General Technical Parameters for VULKAN RATO Series:
Nominal Torque Range:
RATO S series: 16 kNm to 315 kNm
RATO R series: 15.5 kNm to 337.5 kNm
RATO DS series: 8 kNm to 200 kNm
RATO DS+ series: 27.5 kNm to 137.5 kNm
Maximum Torque (Max Torque):
RATO S series: Can reach up to 450 kNm depending on the specific model.
RATO R series: Maximum torque can reach values like 337.5 kNm.
Speed Range:
Typically ranges from 800-450 rpm to 7500-2250 rpm, depending on the model and application.
Temperature Range:
Standard temperature range: up to 50°C.
For some models, it can handle up to 120°C.
Coupling Type:
Shaft-to-Shaft (Shaft – Shaft)
Shaft-to-Flange (Shaft – Flange)
Custom configurations are also available.
Applications:
Oil & Gas: Used for compressors, blowers, and pumps.
Mining: Suitable for heavy-duty equipment like crushers, mills, and stackers.
Iron & Steel: Used in casting machines, rolling mills, and other heavy equipment.
Energy: Used in high-speed applications like wind turbines and hydroelectric generators.
Vibration Damping:
The RATO series is designed to reduce torsional vibrations, which helps improve the stability of the equipment and extends its service life.
